JWS3288-G
Touchfly JWS3288-G industrial motherboard RK3288 quad-core Cortex-A17 64-Bit low-power CPU high-definition display Android 7.1
Manufacturer
Touchfly
Motherboard Model
JWS3288-G
Motherboard Size
151mm x 105mm
Category
Android Industrial Motherboard
CPU
RK3288, Quad-core,1.8GHz,Android 7.1/10.0
GPU
ARM Mail-T764
Memory
2G(4G optional)
Storage
EMMC 16G(8/32/64G optional,maximum 64G)
ROM
4KB EEPROM
Resolution
Maximum 3840*2160
OS
Android 7.1/10.0
Network
4G,Ethernet,WiFi/BT4.0,Wireless peripheral extension
USB
USB HOST*2,USB interface*6
Serial Port
232*2，485*1
Ethernet
10M/100M/1000M adapt Ethernet
WIFI、BT
Built-in WIFI，BT4.0
4G
Unlocked,Support voice call(base on 4G module,Optional)
LVDS
LVDS*1,support 50/60Hz LCD panel
eDP
Support Multi-resolution EDP interface LCD panel
HDMI
HDMI*1, support 1080P@120Hz，4kx2k@60Hz output
Send RFQ
Motherboard Model: JWS3288-G
Required fields are marked *, We’ll respond within 12 hours.
About JWS3288-G Motherboard
JWS3288-G uses Rockchip RK3288 Cortex-A17 quad-core processor, equipped with Android7.1 system, the main frequency is up to 1.8 GHz, powerful performance. Adopt Mali-T764 GPU, support 4K, H.265 hard decoding. Whether it’s games, running scores or The decoding is first-class, and it is your best choice for human-computer interaction and industrial control projects.
Exquisite and small, Strong inner core
Applicable to small-sized smart display terminal equipment: face recognition attendance machine, self-service payment, smart access control, gate, etc.
Six Adavantages
Rich interfae,Support customization,4K hdmi-compatible output, quad-core processor,3G/4G module
Gigabit-Ethernet
Full surge protection,lower processor usage,improe network stability,geater transmission capacity.
API interface debugging code
Support app secondary development,built-in professional remote maintenance software,rich api interfaces.
4K HDMI Video Decoding
4K 3840 x 2160 decoding resolution, EMMC 8G built-in memory, support LCD displays of various LVDS/eDP interfaces and various sizes
